Product Name:? Rod Float Level Transmitter ND101S Series

Brand:? Shanghai Zanke Automation Co., Ltd.

Product Description:?

The rod float level transmitter utilizes a high-performance diffused silicon piezoresistive pressure sensor as the measuring element. It accurately measures the hydrostatic pressure proportional to liquid depth and converts it into a standard (current or voltage) output signal through signal conditioning circuitry, establishing a linear relationship between the output signal and liquid depth for precise level measurement.

Key Features:?

High-precision diffused silicon piezoresistive sensor

Submersible probe design for easy installation

Multi-layer protective structure for enhanced durability

Versatile configurations for industrial applications

Corrosion-resistant stainless steel construction

Applications:?

Liquid level measurement and control in petroleum, chemical, power plants, municipal water supply, and hydrogeological exploration.

Technical Parameters:?

Measuring Range:? 0~0.5m to 200m water column

Power Supply:? 24VDC / 12VDC

Output Signal:? 4~20mA / 1~5V / 0~5V

Compensation Temp:? -10~70℃

Operating Temp:? -40~85℃

Storage Temp:? -40~125℃

Zero Temp Drift:? ±2%FS

Sensitivity Temp Drift:? ±2%FS

Overload Pressure:? 150%FS

Vibration Resistance:? 20g (20-5000Hz)

Shock Resistance:? 100g (11ms)

Accuracy:? 0.1 / 0.3 / 0.5 grade (selectable)

Long-term Stability:? ±0.2%FS/year

Response Time:? ≤1ms (to 90%FS)

Insulation:? 100MΩ/250VDC

Material:?

Housing: Copper-aluminum alloy

Probe: 304 stainless steel (customizable for special media)

Protection Rating:? IP67

Note:? Includes dimensional drawings (mm), wiring diagrams, and selection tables. Custom specifications available based on user requirements.

Disclaimer:?

This content is for reference only. For detailed inquiries, please contact our technical staff.
