Professional English Translation (Technical Specifications):?

Product Name:? LK-136P Submersible Level Transmitter

Brand:? Shanghai Zanke Automation Co., Ltd.

Product Description:?

The LK-136P level transmitter employs high-stability imported sensor chips and precision intelligent transmitter circuitry, utilizing digital signal processing and nonlinear compensation technologies to deliver accurate liquid level measurement. Its hermetically sealed design with waterproof vented cables allows for prolonged submersion in liquids.

Key Features:?

Measurement Technology:?

Laser-trimmed sensor compensation for zero/temperature drift

Reverse polarity and overcurrent protection

Lightning/impact resistance

Structural Design:?

Compact two-wire construction

304/316 stainless steel housing (IP67)

Integrated cable gland for pressure equalization

Technical Parameters:?

Category Specification

Measurement Range? 0-1m to 0-200m (customizable)

Accuracy? ±0.2%FS / ±0.5%FS

Long-term Stability? ≤0.2%FS/year

Operating Temperature? -20°C to +85°C

Output Signals? 4-20mA/0-10V/RS485/HART

Power Supply? 12-30VDC (24VDC recommended)

Overload Capacity? 150% of rated range

Applications:?

Petroleum/chemical storage tanks

Power plant water systems

Municipal water/wastewater treatment

Hydrological monitoring

Installation Notes:?

Suitable for direct immersion in liquids with density ≥0.45g/cm3

Requires avoidance of strong electromagnetic interference

Note:?

This content is for reference only. For detailed inquiries, please contact our technical staff.
